    5-15m³/h Stainless Steel Disc Separator Centrifuge For Biological Pharmaceutical

    Ask Lasest Price
    Brand Name : Juneng
    Model Number : DHC214
    Certification : ISO/CE
    Price : USD18000-55000/set
    Payment Terms : L/C, T/T
    Supply Ability : 30 sets / months
    Delivery Time : 60 days
    • Product Details
    • Company Profile

    5-15m³/h Stainless Steel Disc Separator Centrifuge For Biological Pharmaceutical

    5-15m³/h Stainless Steel Disc Separator Centrifuge For Biological,Pharmaceutical


    Product Description

    Biopharmaceutical as a high-technology has opened up a broad foreground for the development of medical industry and pharmaceutical industry and greatly improved people's lives. Therefore,biotechnology has been identified by the world as the key technologies and new industries in the world's scientific and technological development in 21stcentury.
    The separation quality plays an important role in biopharmaceutical process.Juneng workers with its rich experiences in separation technologies aim at material extraction and purification during production of antibiotics,alkaloidsand hormone, separation and purification of cell proteins as well as blood plasmaseparation. Juneng workers also researchvarious disc separator to meet kinds ofseparation process.

    5-15m³/h Stainless Steel Disc Separator Centrifuge For Biological Pharmaceutical


    Technical data

    Model

    Treatment
    capacity (m³/H)

    Inlet
    pressure (Mpa)

    Outlet
    pressure (Mpa)

    Motor
    power (Kw)

    Weight(Kg)

    Outline
    dimension (mm)

    DHC2113-80.2≤0.21518801800*11200*1910
    DHC2145-150.2≤0.42222001980*1550*2020

    DHC216

    15-25

    0.2

    ≤0.4

    37

    3300

    2100*1900*2400

    DHC611

    3-8

    0.2

    ≤0.2

    18.5

    2000

    1875*1250*1800

    DHC614

    85-150.2≤0.43021002000*1600*1900
    DHC62020-350.2≤0.45536002360*1690*2500

    Successful Applications

    Separation of the extract(such as penicillin, vitamin,Colibacillus, Antibiotics, Hormones,etc.),Vaccine, Microbial

    Concentration, Concentration and Clarification of Fermentation Broth Blood Separation, extraction of Chinese medicine, etc

    Detailed Images

    Parts in the rotating bowl drum

    ll parts & components contacting materials are made of stainless steel, can effectively minimize the corrosion from the materials to be separated, and meet hygienic requirements for food.

    The separator bowl has gone through precise dynamic balance, it can run steadily, with low vibration and noise at operation.

    Vertical shaft and horizontal shaft
    All the parts are made of stainless steel
    High quality machining
    Refining Machine


    Material

    Super stainless steel
    Function
    Running in High speed
    Assembly
    Precision assembly
    Speed
    5000-12000 RPM

    PLC control box

    The separator is equipped with an automatic control cabinet. It consist of an industrial computer and auto overload protector, is highly automated, highly adaptive to change in process, easy to adjust, can greatly reduce the operation labor of workers.

    Product Equipment

    Our company has set-up a first class laboratory for Chemical composition analysis, metallographic analysis, spectrum analysis, performance analysis, radiographinc inspection, magnetism inspecion, ultra-sonic inspection and etc. This is to imply with the latest adva nce instrumentationss and rigorous working attitude to ensure every part of product is stable and reliable.

    Test & Inspection

    QA & QC / Test

    1. Material Test Report 6. Spare Parts Inspection

    2. Magnetic Particle Examination 7. Nondestructive Examination

    3. Metallographic Analysis Sampling 8. Dynamic Balancing Test

    4. Liquid Penetrant Examination 9. Radiographic Examination

    5. Over Speed Test 10. Performance Test

    Company Instruction

    Juneng Group is a large scale manufacturer of industrial products in China. This group principally engaged with the in-house research & development as well as manufacturing of various industrial filters, separators , centrifuges and pumps.


    5-15m³/h Stainless Steel Disc Separator Centrifuge For Biological Pharmaceutical

    5-15m³/h Stainless Steel Disc Separator Centrifuge For Biological Pharmaceutical



    Our philosophies of development:


    * Based on continuous strengthen ourselves with full of innovative ideas


    * 5% of sales revenue is allocated into intensive research


    * 8% of workforce is allocated into development activity


    * Plenty of patent and good quality new products
