Stainless Steel Disc Separator Module 45KW Two-phase For Milk Beer Beverages Pharmaceuticals, And Chemicals

Ask Lasest Price
Brand Name :	Juneng
Model Number :	DBY616
Certification :	ISO/CE
Price :	USD10000-100000/set
Payment Terms :	L/C, T/T
Supply Ability :	30 sets/month
Delivery Time :	50 work days

Add to Cart

Product Details
Company Profile

Stainless Steel Disc Separator Module 45KW Two-phase For Milk Beer Beverages Pharmaceuticals, And Chemicals

Stainless Steel Disc Separator Module 45KW Two-phase For Milk, Beer, Beverages, Pharmaceuticals, and Chemicals

Product Application

DB series disc Separators are full automatic control equipments which have high speed, run steady, hermetic and high efficiency. All parts & components contacting materials are made of stainless steel, can effectively minimize chemical reaction between the materials to be separated and part surface contacted. The separated light phase material will be output by centripetal pump, maximum output pressure can get to 0.3MPa. This machine is fed upper, so it has very low inlet pressure for materials.

Stainless Steel Disc Separator Module 45KW Two-phase For Milk Beer Beverages Pharmaceuticals, And Chemicals

SPECIFICATIONS FOR DBY616 SEPARATOR
Main operating parameters	Treatment capacity	L/H	5000-15000
	Inlet pressure	Mpa	0.2
	Outlet pressure	Mpa	0.1-0.4
	Motor power	Kw	45
Equipment	Weight	Kg	3400
Equipment	Outline dimension	mm	2380x1730x2060

Operation Principle

The separated material will be input into the heart of the separator, i.e. the drum. By the strong centrifugal force field, the material passes the separation partition consists of disk string, the solid in higher specific gravity (heavy phase) will move toward the big end along disk wall, accumulate at the residue-settling area, and be discharged regularly; The liquid in lower specific gravity (light phase) will move toward the small end along disk wall, then assemble at the small centripetal pump, and output by it.

0.3Mpa Beer Disc Separator Centrifuge Machine Discharge Automatically With Ring Valve 0

Juneng Disc Separator on site

Main Features

1) Stable rotating

2) Low noise

3) High separating effect

4) Keep the original nutrition and flavor

Detailed Images

Disc Separator Centrifuge For Purification Of Cell Proteins Blood Plasma Separation 1

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

Packaging
Size	123 (L) * 123(W) * 219 (D)
Weight	1.2 T
Packaging Details	The normal package is wooden box(Size: LWH). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.

Our company

Product Name	Juneng Machinery Factory
Separator	Jiangsu Juneng Machinery Co.,Ltd(South)
Centrifuge	Juneng Machinery (China) Co.,Ltd(Nanjing)
Filter	Jiangsu Juneng Machinery Co.,Ltd(North)
Dryer	Juneng Machinery (China) Co.,Ltd(Nanjing)
Pump	Jiangsu Juneng Machinery Co.,Ltd(South)

Juneng Group is a large scale manufacturer of industrial products in China. This group principally engaged with the in-house research & development as well as manufacturing of various industrial filters, separators , centrifuges and pumps.

The Company now has its 4 production bases with a total capacity of 280,000 square meters in Nanjing city and Yixing City , permanent workforces not less than 1100 people and the production line is well equipped with more than 2000 inits of advanced production equipment and test Instrumentation
